Xcelsus Audio MAGN-4 Amplifier
$899.95
or make 4 interest-free payments of
$224.99 AUD
fortnightly with
More info
MAGN-4 - Designed & Engineered in Sweden
Overview
It is a 4 channel amplifier design to satisfy those discerning music lovers with moderate music level 4 X 88watt and demanding small size W 135mm H 50mm L 310mm. The components selected and the sound tuning is by the designer of famous ULTIMATE ; REFEENCE and TA-2 Amplifiers. That guaranty a certain sound quality level.
Spcifications
- Dimensions 54 x 135 x 308 mm
- Weight 2.4 Kg
- Supply voltage 12 v
- External fuse 60 A
- Internal fuse Not
- Built-in cooling fan Yes
- Maximum current 64 (35) A
- Standby Current Consumption 0.7 (0.35) A
- Bass EQ @ 60 Hz Yes
- High pass filter (on / off) 50-500 Hz
- Low pass filter (on / off) 50-500 Hz
- High level entrance Yes
- Input sensitivity 1-4 V
- Input impedance, high level 45 ohm
- Input impedance, low 5000 ohm
- Operating frequency range 10-60000 Hz
- Attenuation coefficient > 300
- Signal to noise ratio, weighted average 110 dB
- Bridge power 2 channels of 220 W each
- Power at 2 Ohm (RMS) 4 channels of 100 watts
- Power at 4 Ohm (RMS) 4 channels of 85 W each
- Amplifier class A / B
- Number of channels 4
Documentation
